MTW Series Grinding Mill

MTW series trapezium mills are a perfect grinding machine, which could produce 80-400mesh fine powder with large capacity. The biggest model could give 50tph capacity with less powder consumption

Less Occupied Area & Less Investment
Adjustable Output Fineness
60% Lower on Consumption than Ball Mill
Higher Induced Air Efficiency

Chat Online Inquiry

Specification

Model	MTW110	MTW110Z	MTW138Z	MTW175G	MTW215G	MRN158	MRN198	MRN218
Max. Feed Size(mm)	<30	<30	<35	<40	<50	<40	<45	<50
Final size(mm)	1.6-0.045, fineness can reach to 0.038	1.6-0.045, fineness can reach to 0.038	1.6-0.045, fineness can reach to 0.038	1.6-0.045, fineness can reach to 0.038	1.6-0.045, fineness can reach to 0.038	1.6-0.045, fineness can reach to 0.038	1.6-0.045, fineness can reach to 0.038	1.6-0.045, fineness can reach to 0.038
Capacity(t/h)	3-9	3-10	6-17	9.5-25	15-45	7-21	12-33	15-45
Main motor(kW)	55	55	90	160	280	132	220	280
Fan motor(kW)	55	55	110	200	315	132	250	315
Powder classifier motor(kW)	7.5	11	18.5	22	55	22	37	55
Model of electromagnetic vibrating feeder	GZ2F	GZ2F	GZ3F	GZ4F	GZ5F	GZ3F	GZ4F	GZ5F
Power of electromagnetic vibrating feeder(kW)	0.15	0.15	0.2	0.45	0.65	0.45	0.65	0.65
