How to Choose the Best Dust Collection System for Coal Grinding Mills

Introduction

Selecting an optimal dust collection system for coal grinding mills is critical for operational efficiency, environmental compliance, and worker safety. This guide explores key considerations and showcases advanced solutions, including our industry-leading equipment.

Coal grinding mill dust collection system diagram

1. Understanding Dust Generation in Coal Grinding

Coal grinding produces combustible dust particles ranging from 5μm to 100μm. The SCM Ultrafine Mill series achieves D97≤5μm precision while maintaining explosion-proof standards through:

  • Pulse-jet filtration with ≤20mg/m³ emission
  • Explosion vents and pressure relief valves
  • Anti-static filter media

2. Key Selection Criteria

2.1 Filtration Efficiency

Our MTW Series Trapezium Mill integrates a multi-stage dust collector achieving 99.99% efficiency at 325 mesh (45μm), featuring:

Component Specification
Filter Material PTFE-coated polyester
Air-to-Cloth Ratio 1.2:1 (m³/min/m²)
Differential Pressure <1500Pa

Close-up of MTW mill's dust filter assembly

2.2 Explosion Protection

Critical measures include:

  1. Oxygen concentration monitoring
  2. Spark detection systems
  3. Nitrogen inerting capability (optional on SCM models)

3. System Integration

The SCM Ultrafine Mill (0.5-25t/h capacity) demonstrates perfect integration with:

  • Cyclone pre-separators reducing filter load by 85%
  • Variable frequency drive (VFD) controlled fans
  • Automated pulse cleaning at ≤75dB noise level

4. Maintenance Considerations

Our patented designs reduce downtime:

- Quick-release filter cartridge system (30min replacement)
- Wear-resistant ducting (3× industry standard life)
- Remote diagnostic ports

Technician accessing SCM mill dust collection components

5. Recommended Solutions

For coal grinding applications, we recommend:

SCM800 Ultrafine Mill
– 4.5t/h capacity @ 325-2500 mesh
– 75kW main motor with integrated dust control
MTW138Z Trapezium Mill
– 17t/h capacity @ 30-325 mesh
– 110kW pulse-jet dust collector system

Conclusion

Proper dust collection system selection requires balancing filtration efficiency, safety features, and operational costs. Our SCM and MTW series mills provide turnkey solutions meeting international standards like ATEX and NFPA 85.
